How to Deploy Caddy 2.3 with Automatic HTTPS in Docker Swarm

Caddy is an enterprise-ready, open-source web server written in Go that manages HTTPS automatically by default.

In this guide, we will deploy Caddy 2.3 inside a Docker Swarm cluster using Docker Compose to act as an ingress reverse proxy, TLS terminator, and load balancer for containerized microservices.

Prerequisites

Ensure you have the following infrastructure ready before proceeding:

1. A functional Docker Swarm Cluster with distributed shared storage (such as GlusterFS).
2. Administrative access to the Docker Swarm manager node.
3. A registered domain with DNS records pointed to your cluster ingress IP.

Introduction to Caddy

Caddy is an open-source web server written in Go. It relies on the Go standard library for its core HTTP implementations and provides native, zero-configuration TLS management.

Originally developed by Matthew Holt in 2014 and released in 2015, Caddy is maintained by an active open-source community. You can explore the project on the official Caddy GitHub repository.

Caddy significantly reduces infrastructure complexity. It handles ACME certificate issuance, automated renewals, OCSP stapling, static asset delivery, HTTP reverse proxying, and ingress routing from a single static binary.

Caddy runs efficiently in containers because it has no external runtime dependencies—not even libc.

Security Architecture

Caddy provides modern, hardened security primitives out of the box:

• Automated TLS Lifecycle: Acquires and renews Let’s Encrypt or ZeroSSL certificates automatically, with proactive OCSP response stapling.
• Memory Safety: Written in Go, mitigating widespread memory corruption vulnerabilities common in C-based servers.
• Modern Cipher Suites: Defaults to secure protocols (TLS 1.2 and TLS 1.3) with strong cipher suites like ECDHE-ECDSA with AES-256-GCM.
• Protocol Downgrade Mitigation: Implements TLS_FALLBACK_SCSV to protect against protocol downgrade exploits.

Core Capabilities

• Native support for HTTP/1.1, HTTP/2, and HTTP/3.
• Automatic HTTPS provisioning via ACME without external cron jobs or certbot scripts.
• High-performance static file serving.
• Flexible reverse proxying with dynamic load balancing, active health checks, and WebSocket support.
• FastCGI proxy integration for PHP-based workloads.
• Gzip and Zstandard compression.
• Declarative configuration via the human-readable Caddyfile or programmatically via its dynamic JSON API on port 2019.

Persisting Caddy State with GlusterFS

Docker Swarm tasks are inherently ephemeral. If a container restarts or migrates to another node after a host failure, local container filesystem modifications are lost.

To ensure stateful continuity, we use GlusterFS as a distributed, replicated network filesystem mounted across all Swarm worker and manager nodes:

When a file is written to the shared mount point, it is replicated across the cluster. If a node fails, the service restarts on another node with zero data loss.

For Caddy, we must persist three directories:

• /data: Holds acquired ACME certificates, private keys, and account metadata.
• /config: Stores the running configuration state and autosaves.
• /var/log/caddy: Retains access and error logs for auditing.

Create the persistent directories on your shared storage mount:

cd /mnt
sudo mkdir -p caddydata caddyconfig caddylogs

---

Prepare the Swarm Environment

First, create a Docker overlay network. This network acts as the communication plane connecting Caddy to backend application services.

Run the following commands on your Swarm manager node:

docker network create -d overlay --attachable caddy

Next, create a dedicated project directory:

cd /opt
sudo mkdir -p caddy
cd caddy
sudo touch Caddyfile caddy.yml

Caddyfile Configuration

Open Caddyfile using your text editor:

sudo nano Caddyfile

Paste your site blocks or template configuration. Here is a baseline configuration serving static files with template rendering:

localhost {
    templates
    file_server
}

Docker Compose Stack Definition

Open caddy.yml:

sudo nano caddy.yml

Add the following stack specification:

version: "3.7"

services:
  caddy:
    image: tuneitme/caddy:latest
    ports:
      - "80:80"
      - "443:443"
    networks:
      - caddy
    volumes:
      - ./Caddyfile:/etc/caddy/Caddyfile
      - /mnt/caddydata:/data
      - /mnt/caddyconfig:/config
      - /mnt/caddylogs:/var/log/caddy
      - /mnt/blog:/etc/caddy/html/blog
    environment:
      - ACME_AGREE=true
    deploy:
      replicas: 1
      placement:
        constraints:
          - node.role == manager
      update_config:
        parallelism: 2
        delay: 10s
      restart_policy:
        condition: on-failure

volumes:
  caddydata:
    driver: "local"
  caddyconfig:
    driver: "local"
  caddylogs:
    driver: "local"
  blog:
    driver: "local"

networks:
  caddy:
    external: true

---

Deploy Caddy to the Swarm

Deploy the stack using the Docker CLI:

docker stack deploy --compose-file caddy.yml caddy

Verify that the Caddy service task is active and running on the manager node:

docker stack ps caddy

Inspect the service logs to verify TLS certificate issuance and initialization:

docker service logs -f caddy_caddy

Summary

Caddy delivers an automated, self-healing TLS edge router with minimal configuration overhead. In upcoming tutorials, we will connect downstream applications—including Ghost, Nextcloud, and MariaDB—directly to this caddy overlay network for automatic routing and encryption.
